LED Pressure Transmitter
◆Complete smart 4~20mA working pattern, 4-digit 0.56" LED display.
◆Provide rapid calibration function, parameter modification function, key modification function, suitable for the special needs of various customers.
◆Full digital calibration, without any movable potentiometer, lower temperature drift.
◆Stronger anti-interference design, suitable for all kinds of electromagnetic industrial environment.
◆A unique non-linearity correction function, ideal for removing sensor's non-linearity errors.
◆Case and circuit board are made through professional mold, firm and reliable.
◆Special strong anti-interference design, especially suitable for the heating and water supply industry.
◆Cable outlet port using a waterproof joint, protection IP65.
LED Pressure Transmitter
Description of LED pressure transmitter
UPB6 LED pressure transmitter adopts the pressure sensor UPX19 with stainless steel isolation diaphragm as the pressure measuring element, with good performance in long term stability and reliability.
With 4-digit LED indicator, the pressure value can be read real time.
UPB6 LED pressure transmitter is widely used in hydropower, petroleum, chemical, hydraulic and other industries to measure the pressure of the fluid medium.
Features of LED pressure transmitter
◆Complete smart 4~20mA working pattern 4-digit 0.56" LED display.
◆Provide rapid calibration function, parameter modification function, key modification function, suitable for the special needs of various customers.
◆Full digital calibration, without any movable potentiometer, lower temperature drift.
◆Stronger anti-interference design, suitable for all kinds of electromagnetic industrial environment.
◆A unique non-linearity correction function, ideal for removing sensor's non-linearity errors
◆Case and circuit board are made through professional mold, firm and reliable
◆Special strong anti-interference design, especially suitable for the heating and water supply industry
◆Cable outlet port using a waterproof joint, protection IP65
Specifications of LED pressure transmitter
| pressure ranges | -1...0~0.1...1000bar |
| overload pressure | 150%FS |
| output signal | 4~20mA two-wire |
| accuracy | 0.25%FS, 0.5%FS |
| load resistance | RL =(U-12V)/0.02A (4~20mA current output) U-loop voltage(V) |
| long-term stability | <0.2%FS/year |
| supply voltage | 12~32VDC |
| operating temperature range | -30~+80℃ |
| temperature coefficient of zero | 0.2%FS/10℃ |
| temperature coefficient of span | 0.2%FS/10℃ |
| process connection | G1/2 or others |
| housing material | ABS engineering plastic |
| sealing material | nitrile rubber |
| dial meter | 82mm |
| display speed | 10 times/sec. |
| display method | 4-digit 0.56 LED Red color highlight |
| display range | -1999~9999 |
