Stainless Steel Pressure Sensor
1. All-welded structure, suitable for measuring many kinds of media.
2. Full stainless steel 316L material.
3. Measuring ranges:-1...0 0.2bar…1000bar.
4. Excitation: constant current, or constant voltage.
5. Pressure type: gauge pressure, absolute pressure and sealed.
Stainless Steel Pressure Sensor
Description of stainless steel pressure sensor
UPX22 all-welded pressure sensor is constructed by welding general pressure sensor UPX19 into
pressure port with standard or specific thread. This structure avoids the hidden trouble or incompetability caused to O-ring in bad conditions. The sensor back end (electrical side) is suppled with M25*1 male thread, it will be easy for use to make transmitter with this design.
UPX22 all-welded pressure sensor can be customized as special requests.
UPX22 pressure sensor is widely used in petroleum industry, chemical industry, process control, hydraulic system, pressure examination measuring instruments, pressure calibration instruments, refrigeration plant and air-conditioning system as well as aviation navigation examination etc.
Features of stainless steel pressure sensor
◇All-welded structure, suitable for measuring many kinds of media;
◇Full stainless steel 316L material;
◇Measuring ranges:-1...0 0.2bar…1000bar;
◇Excitation: constant current, or constant voltage;
◇Pressure type: gauge pressure, absolute pressure and sealed gauge pressure.
Specifications of stainless steel pressure sensor
| pressure medium | gas or liquids compatible with stainless steel |
| pressure ranges | -1...0~0.1...1000 bar |
| pressure type | gauge(G), absolute(A), sealed gauge(S) |
| overload pressure | 150%FS(<3.5MPa);150%FS("3.5MPa) |
| output signal | ≥70mV(typical) |
| accuracy | 0.25%FS(standard), 0.5%FS |
| zero offset | ≤±3mV |
| long-term stability | <0.2%FS/year |
| excitation | 1.5mA or 10V DC (1.5mA standard) |
| compensated temperature range | -10~+70℃ |
| operating temperature range | -40~+125℃ |
| storage temperature range | -40~+125℃ |
| temperature coefficient of zero | 0.25%FS/10℃ |
| temperature coefficient of span | 0.2%FS/10℃ |
| input/output resistance | 2.5~8kΩ |
| insulation resistance | 500MΩ@100VDC |
| response time(10%~90%) | ≤1ms |
| electrical connection | 4 colored silicon rubber flexible wire or 6 pin(gold coated kovar wires) |
| housing and diaphragm material | 316L |
