Coolsour Auto Reset Dual Pressure Control, Refrigeration Fitting

1. flame explosion-proof housing design.
2. 4-digit LED display, without apparent value error.
3. 4-channel control point relay output 220V 3A.
4. 4~20mA standard output (optional).
5. 4-channel control point can be set on the spot.
6. Power supply optional: 24V DC or 220V AC.
7. RS485 interface, for easy networking(optional).

Send Inquiry

Chat Now

We always keep our promises and operate in compliance, so that every Load Pin, Silicon Pressure Sensor, Flush Membrane Pressure Sensor is the result of our promises. Our global network of suppliers and partners ensures that we can provide the best products at the most competitive prices. Our company is dedicated to delivering customized solutions that exceed our customers' expectations.

Digital Oil Pressure Switch Controller

Description

UPS5 digital oil pressure switch controller is using high quality silicon pressure sensor as sensing element, this smart digital instrument has combined functions like pressure measurement, display, output and 4-way relay controls.

This digital oil pressure switch controller is suitable for flow medium pressure measurement and control, and transfer remote analouge output signal 4~20mA or digital RS485(MODBUS RTU) for easy networking.

UPS5 digital oil pressure switch controller is widely used in water and electricity industry, petroleum industry, chemical industry etc, for the level measurement and control of many kinds of fluids or gas on the spot.

Features

◆flame explosion-proof housing design;

◆4-digit LED display, without apparent value error;

◆4-channel control point relay output 220V 3A;

◆4 20mA standard output (optional);

◆4-channel control point can be set on the spot;

◆Power supply optional: 24V DC or 220V AC;

◆RS485 interface, for easy networking(optional)

Specifications

pressure medium	gas or liquid compatible with stainless steel
pressure ranges	-1...0~0.1...1000bar
overload pressure	150%FS
output signal	4~20mA(option)
controlling accuracy	0.25%FS(standard),0.5%FS
display	0.56" 4-digit LED
display range	-1999~9999
display accuracy	0.1%FS
long-term stability	<0.2%FS/year
supply voltage	24V DC or 220V AC
compensated temperature range	-10~+70℃
media temperature range	-40~+120℃
coefficient temperature	0.2%FS/10℃
process connection	M20x1.5 or others
material of housing	cast aluminium
material of wetted part	1Cr18Ni9Ti
protection	IP66
