Atex Explosion-Proof Water Oil Liquids Tank Iot Level Sensor

Atex Explosion-Proof Water Oil Liquids Tank Iot Level Sensor

★ Intrinsic safety, or flame-proof safety optional;
★ Wide application scope long service life;
★ IP68 protection;
★ Against thunder stroke, against radio-frequency interference.

In order to accelerate the transformation and innovation, we actively promote the research, development and application of new technologies and new series of the 4 digit Pressure Transmitter, Pressure Transducer, Flush Pressure Transducer . With your support and help, we are willing to develop together with you with our honest attitude and redoubled efforts. We are dedicated to upholding the highest standards of business ethics and professionalism. We have always been open-minded to learn from others, and a number of enterprises for in-depth cooperation. We are committed to social welfare and participate in charity activities, and do our best to build a harmonious society.

Oil Level Sensor

Description

ULB6 oil level sensor is made from stainless steel with rigid and robust construction. The protection case with a small hole not only protect the diaphragm, but also let the liquids contact the diaphragm freely. The exquisite sealing technology as well as good assembly techniques guarantee ULB6 oil level sensor's outstanding quality & performance.

This oil level sensor has a waterproof cable with vent hose which is designed for submersible applications.

Features

★ Intrinsic safety, or flame-proof safety optional;

★ Wide application scope long service life;

★ IP68 protection;

★ Against thunder stroke, against radio-frequency interference.

Specifications

measuring ranges 0~1mH2O...200mH2O
output signal 4~20mA, 0~5V, 0~10V, 1~5V
accuracy 0.1%FS,0.25%FS(standard), 0.5%FS
load resistance RL=(U-12V)/0.02A(4~20mA current output) U-loop voltage (V)
supply voltage 12~36VDC
compensated temperature range -10~70℃
storage temperature range -40~100℃
electrical connection Φ7.2mm shielded cable with vent hose
material of pressure membrane 316L or tantalum
sealing n-Butyronitrile or fluoro-rubber sealing ring

Application

ULB6 oil level sensor is widely applied in petroleum, chemical, metallurgy, hydrology exploration etc.

液位变送器的应用总图

The company's development vision is to become one of the most core competitive modern enterprises in the field of Atex Explosion-Proof Water Oil Liquids Tank Iot Level Sensor! Our corporate culture is focused, innovative and win-win. Our corporate goal is to provide customers with high-quality and stable products while providing high-quality technical services. Our company has established a nationwide marketing network and a diversified service platform. Looking to the future, we have established the strategic goal of promoting trade and building a group with international competitiveness, striving to build a first-class trading group with outstanding reputation, outstanding brand, financial soundness and excellent efficiency.
