3 Wire Rtd 4-20mA PT100 Temperature Transmitter

1. Range: -200 ~1600℃;
2. High accuracy,anti-interference, good long-term stability;
3. Integrated structure,can display its real-time measuring value.

Send Inquiry

Chat Now

We are committed to the development of domestic products, provide high-quality Liquid Pressure Transmitter, RS485 Temperature Transmitter, Capacitive Differential Pressure Transmitter for domestic and international markets, and have formed large-scale production. We understand the importance of communication and strive to maintain open and transparent lines of communication with our clients at all times. We will continue to play a leading role, come to our mission and social responsibility, and continue to work hard.

4-20mA temperature transmitter

Description

UTB9 integrated 4-20mA temperature transmitter thermocouple or thermal resistor as temperature sensitive element, it can measure temperature of all kinds of liquid, steam and gas medium from -200 to 1600℃, and transform thermocouple's or thermal resistance's signal to 4~20mA standard signal, simultaneously has real-time indication function on the spot.

UTB9 integrated 4-20mA temperature transmitter has LCD or LED display. UTB8 uses integrated electric circuit, which guarantee its stable signal and clear display, this is very convenient to calibrate and inspect the gauges on the scene.

Features

◆Range: -200 ~1600℃;

◆High accuracy, anti-interference, good long-term stability;

◆Integrated structure, can display its real-time measuring value.

Specifications

measuring	gas or liquids compatible to stainless steel
temperature ranges	thermocouple: E,K,S,B thermal resistor: PT100,Cu50
insert depth	50mm~2000mm(as customer's request)
accuracy	thermal resistor:0.5%FS(standard);thermocouple: 0.75%FS
output signal	4~20mA
long-term stability	<0.25%FS/year
supply voltage	24V±10% DC
load resistance	RL(max.) =(V-12)/0.02, V:power supply of transmitter
insulation resistance	100MΩ@50VDC
ambient temperature range	-30~+80℃
display	LCD or LED
temperature coefficient of zero	0.2%FS/10℃
temperature coefficient of span	0.2%FS/10℃
process connection	G1/2 or others
electrical connection	M20×1.5 (female)
material of wetted part	1Cr18Ni9Ti stainless steel
material of housing	cast alaluminium
maximum pressure	10MPa
protection	IP65

Application

UTB9 industrial 4-20mA temperature transmitter has been widely used in chemical industry, petroleum industry, metallurgy industry, light industry, food, electric power, and energy management etc.
