Temperature Pressure Sensor
1. Measure pressure and temperature simultaneously;
2. Super-high cost effective;
3. Have gauge pressure, absolute pressure and sealed gauge pressure;
4. Imported pressure silicon dies
Temperature Pressure Sensor
Model: UPX23
Description
UPX23 temperature pressure sensor is based on UPX19 pressure sensor and in-built Pt100 resistor, which realizes the temperature and pressure measurement simultaneously.
This temperature pressure sensor can match the requirement that need temperature and pressure measurement at same time. Meanwhile, the in-built Pt100 resistor can meet the requirement of further temperature compensation for sensors.
Features
* Measure pressure and temperature simultaneously;
* Super-high cost effective;
* Have gauge pressure, absolute pressure and sealed gauge pressure;
* Imported pressure silicon dies.
Specifications
| pressure medium | gas, viscous fluid or fluid with grains compatible to stainless steel |
| pressure ranges | -1...0~0.1...1000bar |
| pressure type | gauge(G), absolute(A), sealed gauge(S) |
| temperature sensor | Pt100 |
| overload pressure | 150%FS |
| output signal | ≥70mV(typical) |
| accuracy | 0.25%FS(standard), 0.5%FS |
| excitation | 1.5mA or 5V |
| compensated temperature range | -10~+70℃ |
| operating temperature range | -40~+125℃ |
| input/output resistance | 2~6kΩ |
| electrical connection | 6 colored silicon rubber flexible wire |
| wetted part material | 316 |
| diaphragm material | 316L |
| filled oil | silicon oil |
