Digital Pressure Switch
1. 4 digit LED Switch value can be set from zero to full scale freely.
2. The outer case is equipped with light emitting diode (LED), is easy for abserving operation.
3. Operation is easy; the pressed key is for adjustment and parameters setting on the spot.
4. Two-way switch output, 1.2A loading capacity.
5. 4~20mA analog output (optional).
Digital Pressure Switch
Description
UPS2 digital pressure switch is pressure measurement & control product with intelligent digital display, it is combined the functions of pressure measurement, display, output and control. This product is made with entire electronic structure, and built isolated-membrane pressure sensor in its front end. Its output signal is amplified through high accuracy & low temperature drift amplifer, then is input high accuracy A/D converter, and processed by microprocessor, the processed signal controls two-way switch, to realize the pressure measurement and control for systems.
The use of UPS2 digital pressure switch is very flexible. UPS2's operation and adjustment is simple and easy, meanwhile, this product also has good reliability and safety.
Features
◆4 digit LED Switch value can be set from zero to full scale freely.
◆The outer case is equipped with light emitting diode (LED), is easy for abserving operation.
◆Operation is easy; the pressed key is for adjustment and parameters setting on the spot.
◆Two-way switch output, 1.2A loading capacity.
◆4~20mA analog output (optional).
Specifications
| pressure medium | gas or liquid compatible with stainless steel |
| pressure ranges | -1...0~0.1...1000bar |
| overload pressure | 150%FS |
| output signal | 4~20mA(option) |
| control accuracy | 0.25%FS(standard) |
| display range | -1999~9999 |
| display mode | 4 digit LED |
| switch type | PNP (standard) or NPN |
| supply voltage | 18~32V DC |
| ambient temperature range | -30~+80℃ |
| media temperature range | -40~+100℃ |
| temperature coefficient | 0.2%FS/10℃ |
| service life of switch | >1million times |
| power consumption | <3W |
| load capacity | <24V/1.2A |
| process connection | G1/4 or others |
| electrical connection | M12x1 connector or others |
| material of wetted part | 1Cr18Ni9Ti |
| protection | IP65 |
Application
UPS2 digital pressure switch is widely used in water and electricity industry, petroleum industry, chemical industry, machinery industry etc, for the pressure measurement and control of many kinds of fluids or gas.
